Exploring Generative AI in conversational experiences: An Introduction with Amazon Lex, Langchain, and SageMaker Jumpstart

TutoSartup excerpt from this article:
See the following code: def dispatch_lexv2(request): “””Summary Args: request (dict): Lambda event containing a user’s input chat message and context (historical conversation) Uses the LexV2 sessions API to manage past inputs https://docs…dispatch_intent()def dispatc…

Customers expect quick and efficient service from businesses in today’s fast-paced world. But providing excellent customer service can be significantly challenging when the volume of inquiries outpaces the human resources employed to address them. However, businesses can meet this challenge while providing personalized and efficient customer service with the advancements in generative artificial intelligence (generative AI) powered by large language models (LLMs).

Generative AI chatbots have gained notoriety for their ability to imitate human intellect. However, unlike task-oriented bots, these bots use LLMs for text analysis and content generation. LLMs are based on the Transformer architecture, a deep learning neural network introduced in June 2017 that can be trained on a massive corpus of unlabeled text. This approach creates a more human-like conversation experience and accommodates several topics.

As of this writing, companies of all sizes want to use this technology but need help figuring out where to start. If you are looking to get started with generative AI and the use of LLMs in conversational AI, this post is for you. We have included a sample project to quickly deploy an Amazon Lex bot that consumes a pre-trained open-source LLM. The code also includes the starting point to implement a custom memory manager. This mechanism allows an LLM to recall previous interactions to keep the conversation’s context and pace. Finally, it’s essential to highlight the importance of experimenting with fine-tuning prompts and LLM randomness and determinism parameters to obtain consistent results.

Solution overview

The solution integrates an Amazon Lex bot with a popular open-source LLM from Amazon SageMaker JumpStart, accessible through an Amazon SageMaker endpoint. We also use LangChain, a popular framework that simplifies LLM-powered applications. Finally, we use a QnABot to provide a user interface for our chatbot.

First, we start by describing each component in the preceding diagram:

  • JumpStart offers pre-trained open-source models for various problem types. This enables you to begin machine learning (ML) quickly. It includes the FLAN-T5-XL model, an LLM deployed into a deep learning container. It performs well on various natural language processing (NLP) tasks, including text generation.
  • A SageMaker real-time inference endpoint enables fast, scalable deployment of ML models for predicting events. With the ability to integrate with Lambda functions, the endpoint allows for building custom applications.
  • The AWS Lambda function uses the requests from the Amazon Lex bot or the QnABot to prepare the payload to invoke the SageMaker endpoint using LangChain. LangChain is a framework that lets developers create applications powered by LLMs.
  • The Amazon Lex V2 bot has the built-in AMAZON.FallbackIntent intent type. It is triggered when a user’s input doesn’t match any intents in the bot.
  • The QnABot is an open-source AWS solution to provide a user interface to Amazon Lex bots. We configured it with a Lambda hook function for a CustomNoMatches item, and it triggers the Lambda function when QnABot can’t find an answer. We assume you have already deployed it and included the steps to configure it in the following sections.

The solution is described at a high level in the following sequence diagram.

Major tasks performed by the solution

In this section, we look at the major tasks performed in our solution. This solution’s entire project source code is available for your reference in this GitHub repository.

Handling chatbot fallbacks

The Lambda function handles the “don’t know” answers via AMAZON.FallbackIntent in Amazon Lex V2 and the CustomNoMatches item in QnABot. When triggered, this function looks at the request for a session and the fallback intent. If there is a match, it hands off the request to a Lex V2 dispatcher; otherwise, the QnABot dispatcher uses the request. See the following code:

def dispatch_lexv2(request):
    """Summary
    Args:
        request (dict): Lambda event containing a user's input chat message and context (historical conversation)
        Uses the LexV2 sessions API to manage past inputs https://docs.aws.amazon.com/lexv2/latest/dg/using-sessions.html

    Returns:
        dict: Description
    """
    lexv2_dispatcher = LexV2SMLangchainDispatcher(request)
    return lexv2_dispatcher.dispatch_intent()

def dispatch_QnABot(request):
    """Summary

    Args:
        request (dict): Lambda event containing a user's input chat message and context (historical conversation)

    Returns:
        dict: Dict formatted as documented to be a lambda hook for a "don't know" answer for the QnABot on AWS Solution
        see https://docs.aws.amazon.com/solutions/latest/QnABot-on-aws/specifying-lambda-hook-functions.html
    """
    request['res']['message'] = "Hi! This is your Custom Python Hook speaking!"
    qna_intent_dispatcher = QnASMLangchainDispatcher(request)
    return qna_intent_dispatcher.dispatch_intent()

def lambda_handler(event, context):
    print(event)
    if 'sessionState' in event:
        if 'intent' in event['sessionState']:
            if 'name' in event['sessionState']['intent']:
                if event['sessionState']['intent']['name'] == 'FallbackIntent':
                    return dispatch_lexv2(event)
    else:
        return dispatch_QnABot(event)

Providing memory to our LLM

To preserve the LLM memory in a multi-turn conversation, the Lambda function includes a LangChain custom memory class mechanism that uses the Amazon Lex V2 Sessions API to keep track of the session attributes with the ongoing multi-turn conversation messages and to provide context to the conversational model via previous interactions. See the following code:

class LexConversationalMemory(BaseMemory, BaseModel):

    """Langchain Custom Memory class that uses Lex Conversation history

    Attributes:
        history (dict): Dict storing conversation history that acts as the Langchain memory
        lex_conv_context (str): LexV2 sessions API that serves as input for convo history
            Memory is loaded from here
        memory_key (str): key to for chat history Langchain memory variable - "history"
    """
    history = {}
    memory_key = "chat_history" #pass into prompt with key
    lex_conv_context = ""

    def clear(self):
        """Clear chat history
        """
        self.history = {}

    @property
    def memory_variables(self) -> List[str]:
        """Load memory variables

        Returns:
            List[str]: List of keys containing Langchain memory
        """
        return [self.memory_key]

    def load_memory_variables(self, inputs: Dict[str, Any]) -> Dict[str, str]:
        """Load memory from lex into current Langchain session memory

        Args:
            inputs (Dict[str, Any]): User input for current Langchain session

        Returns:
            Dict[str, str]: Langchain memory object
        """
        input_text = inputs[list(inputs.keys())[0]]

        ccontext = json.loads(self.lex_conv_context)
        memory = {
            self.memory_key: ccontext[self.memory_key] + input_text + "nAI: ",
        }
        return memory

The following is the sample code we created for introducing the custom memory class in a LangChain ConversationChain:

# Create a conversation chain using the prompt,
# llm hosted in Sagemaker, and custom memory class
self.chain = ConversationChain(
    llm=sm_flant5_llm,
    prompt=prompt,
    memory=LexConversationalMemory(lex_conv_context=lex_conv_history),
    verbose=True
)

Prompt definition

A prompt for an LLM is a question or statement that sets the tone for the generated response. Prompts function as a form of context that helps direct the model toward generating relevant responses. See the following code:

# define prompt
prompt_template = """The following is a friendly conversation between a human and an AI. The AI is
talkative and provides lots of specific details from its context. If the AI does not know
the answer to a question, it truthfully says it does not know. You are provided with information
about entities the Human mentions, if relevant.

Chat History:
{chat_history}

Conversation:
Human: {input}
AI:"""

Using an Amazon Lex V2 session for LLM memory support

Amazon Lex V2 initiates a session when a user interacts to a bot. A session persists over time unless manually stopped or timed out. A session stores metadata and application-specific data known as session attributes. Amazon Lex updates client applications when the Lambda function adds or changes session attributes. The QnABot includes an interface to set and get session attributes on top of Amazon Lex V2.

In our code, we used this mechanism to build a custom memory class in LangChain to keep track of the conversation history and enable the LLM to recall short-term and long-term interactions. See the following code:

class LexV2SMLangchainDispatcher():

    def __init__(self, intent_request):
        # See lex bot input format to lambda https://docs.aws.amazon.com/lex/latest/dg/lambda-input-response-format.html
        self.intent_request = intent_request
        self.localeId = self.intent_request['bot']['localeId']
        self.input_transcript = self.intent_request['inputTranscript'] # user input
        self.session_attributes = utils.get_session_attributes(
            self.intent_request)
        self.fulfillment_state = "Fulfilled"
        self.text = "" # response from endpoint
        self.message = {'contentType': 'PlainText','content': self.text}

class QnABotSMLangchainDispatcher():
    def __init__(self, intent_request):
        # QnABot Session attributes
        self.intent_request = intent_request
        self.input_transcript = self.intent_request['req']['question']
        self.intent_name = self.intent_request['req']['intentname']
        self.session_attributes = self.intent_request['req']['session']

Prerequisites

To get started with the deployment, you need to fulfill the following prerequisites:

Deploy the solution

To deploy the solution, proceed with the following steps:

  1. Choose Launch Stack to launch the solution in the us-east-1 Region:
    Launch CloudFormation stack
  2. For Stack name, enter a unique stack name.
  3. For HFModel, we use the Hugging Face Flan-T5-XL model available on JumpStart.
  4. For HFTask, enter text2text.
  5. Keep S3BucketName as is.

These are used to find Amazon Simple Storage Service (Amazon S3) assets needed to deploy the solution and may change as updates to this post are published.

Solution Stack parameteres

  1. Acknowledge the capabilities.
  2. Choose Create stack.

There should be four successfully created stacks.

List of stacks created by the cloudformation stack

Configure the Amazon Lex V2 bot

There is nothing to do with the Amazon Lex V2 bot. Our CloudFormation template already did the heavy lifting.

Configure the QnABot

We assume you already have an existing QnABot deployed in your environment. But if you need help, follow these instructions to deploy it.

  1. On the AWS CloudFormation console, navigate to the main stack that you deployed.
  2. On the Outputs tab, make a note of the LambdaHookFunctionArn because you need to insert it in the QnABot later.

Lambdahook function for QnABot configuration

  1. Log in to the QnABot Designer User Interface (UI) as an administrator.
  2. In the Questions UI, add a new question.

Add a questiong in the Questions UI

  1. Enter the following values:
    • IDCustomNoMatches
    • Questionno_hits
    • Answer – Any default answer for “don’t know”
  2. Choose Advanced and go to the Lambda Hook section.
  3. Enter the Amazon Resource Name (ARN) of the Lambda function you noted previously.

ARN to link with the Amazon Lex Bot

  1. Scroll down to the bottom of the section and choose Create.

You get a window with a success message.

Succes message after adding lambda hook to the qnabot

Your question is now visible on the Questions page.

new question created

Test the solution

Let’s proceed with testing the solution. First, it’s worth mentioning that we deployed the FLAN-T5-XL model provided by JumpStart without any fine-tuning. This may have some unpredictability, resulting in slight variations in responses.

Test with an Amazon Lex V2 bot

This section helps you test the Amazon Lex V2 bot integration with the Lambda function that calls the LLM deployed in the SageMaker endpoint.

  1. On the Amazon Lex console, navigate to the bot entitled Sagemaker-Jumpstart-Flan-LLM-Fallback-Bot.
    This bot has been configured to call the Lambda function that invokes the SageMaker endpoint hosting the LLM as a fallback intent when no other intents are matched.
  2. Choose Intents in the navigation pane.

Amazon Lex Navigation Pane

On the top right, a message reads, “English (US) has not built changes.”

  1. Choose Build.
  2. Wait for it to complete.

Finally, you get a success message, as shown in the following screenshot.

Success message after bot config

  1. Choose Test.

A chat window appears where you can interact with the model.

Interaction with bot window

We recommend exploring the built-in integrations between Amazon Lex bots and Amazon Connect. And also, messaging platforms (Facebook, Slack, Twilio SMS) or third-party Contact Centers using Amazon Chime SDK and Genesys Cloud, for example.

Test with a QnABot instance

This section tests the QnABot on AWS integration with the Lambda function that calls the LLM deployed in the SageMaker endpoint.

  1. Open the tools menu in the top left corner.

Opening the tools menu

  1. Choose QnABot Client.

QnABot client selection

  1. Choose Sign In as Admin.

QnABot client sign in window

  1. Enter any question in the user interface.
  2. Evaluate the response.

QnAbot client UI

Clean up

To avoid incurring future charges, delete the resources created by our solution by following these steps:

  1. On the AWS CloudFormation console, select the stack named SagemakerFlanLLMStack (or the custom name you set to the stack).
  2. Choose Delete.
  3. If you deployed the QnABot instance for your tests, select the QnABot stack.
  4. Choose Delete.

Conclusion

In this post, we explored the addition of open-domain capabilities to a task-oriented bot that routes the user requests to an open-source large language model.

We encourage you to:

  • Save the conversation history to an external persistence mechanism. For example, you can save the conversation history to Amazon DynamoDB or an S3 bucket and retrieve it in the Lambda function hook. In this way, you don’t need to rely on the internal non-persistent session attributes management offered by Amazon Lex.
  • Experiment with summarization – In multiturn conversations, it’s helpful to generate a summary that you can use in your prompts to add context and limit the usage of conversation history. This helps to prune the bot session size and keep the Lambda function memory consumption low.
  • Experiment with prompt variations –  Modify the original prompt description that matches your experimentation purposes.
  • Adapt the language model for optimal results – You can do this by fine-tuning the advanced LLM parameters such as randomness (temperature) and determinism (top_p) according to your applications. We demonstrated a sample integration using a pre-trained model with sample values, but have fun adjusting the values for your use cases.

In our next post, we plan to help you discover how to fine-tune pre-trained LLM-powered chatbots with your own data.

Are you experimenting with LLM chatbots on AWS? Tell us more in the comments!
